High-Efficiency Mechanical Articulation: CPWR/CPDR Quick-Locked Cross Universal Joint

The CPWR/CPDR Series Factory Manufactured Auto Part Cardan Joint is engineered to deliver highly secure, rapid-installation power transmission across heavy-duty industrial and agricultural machinery configurations. In operations requiring frequent maintenance teardowns or quick equipment changeovers, traditional fixed couplers increase downtime exponentially. The quick locking universal joint resolves this bottleneck by utilizing an integrated fast-locking mechanism. This allows operators to couple or decouple shafts in seconds without compromising mechanical rigidity. It is highly effective for PTO drivelines, automotive machinery links, stepper motor assemblies, construction infrastructure, and agricultural power take-off setups.

As detailed in the technical profile in universal joint, the primary components are built using a high-performance multi-material matrix: the outer fork utilizes premium 42CrMo alloy steel

(42crmo) treated with an advanced quenching process, while the central cross pin is forged from rugged 20CR steel. This National Standard metric assembly accommodates a 30 mm bore diameter, an overall length of 350 mm, and an exceptional operating angle of 45 degrees while supporting operational velocity bands from 0 to 4,000 RPM.

Core Product Advantages / Unique Selling Points

• Advanced Quick-Locked Mechanism: Built with a specialized fast-locking type configuration that speeds up component coupling, reducing assembly turnaround times on complex machinery lines.

• Heavy-Duty Multi-Material Metallurgy: Engineered with a hardened 42CrMo quenched body for maximum torsional yield strength, combined with a 20CR steel cross pin to absorb repeated shock impacts.

• Broad 45-Degree Angular Flex: Provides clean, unhindered mechanical articulation up to a maximum 45-degree operating angle, keeping power delivery smooth through steep alignment shifts.

• Secure Double-Locking Hub Setup: Integrates a reliable pin and keyway shaft fixing method to prevent axial sliding or rotational slippage under high reverse loading pressures.

• Versatile Velocity & Torque Envelope: Operates smoothly across a wide dynamic spectrum, handling an allowable torque range from 11.2 to 550 N·m with speed capabilities up to 4,000 RPM (speeds above 1,000 RPM can be precision-customized).

• Certified Factory Pipeline with 1-Pcs MOQ: Manufactured in our ISO9001 and BV certified facility in Dongguan, Guangdong, China, backed by a 1-year structural warranty and an accessible 1 Pcs Minimum Order Quantity.

• Complete OEM, ODM, & OBM Program Tracks: Provides broad customization support to alter bore tolerances, specific lengths, overall metric shapes, and keyways to match your exact equipment blueprints.

Technical Specifications Table
