Heavy-Duty SWC-WD Short Type Cardan Shaft Couplings

High-Torque Flanged Cross Shaft Universal Couplings for Heavy Machinery & Rolling Mills

Apex Coupling’s SWC-WD Series Cardan Shaft Couplings feature a compact, short non-telescopic design constructed from high-strength forged steel. Engineered for heavy industrial drive lines operating under extreme torque loads and space limitations, the SWC-WD coupling delivers high transmission efficiency, long fatigue life, and large angular compensation ranging from 15° to 25°.

• Model Series: SWC-WD (Short / Non-Telescopic Design)

• Rotation Diameter Range: 100 mm to 620 mm

• Nominal Torque Capacity: 1.25 kN·m to 1,000 kN·m (Heavy Duty)

• Axis Angle Compensation: 15° to 25°

• Material & Structure: Forged Alloy Steel Flange Hubs with Bearing Steel Cross Spider

• Mounting Type: Standard Industrial Flange Connection (Quick & Easy Assembly)

• Protection & Finish: Industrial Paint Coating / Sandblasted Finish (IP65 Level Protection)

• MOQ: 1 Set (Custom flange dimensions & non-standard sizes supported)

2. Key Features & Technical Advantages

Why Choose Apex SWC-WD Cardan Shaft Couplings?

1. Ultra-Compact Short Design: The WD series eliminates the spline sliding section, resulting in an exceptionally short axial length for high-torque power transfer in tight machine layouts.

2. High-Strength Forged Steel Construction: Manufactured with premium forged steel hubs and high-grade bearing steel cross spiders to handle severe peak shock loads and continuous operation.

3. High Torque & Large Angular Offset: Capable of transmitting nominal torques up to 1,000 kN·m with dynamic angular flexibility between 15° and 25°.

4. Convenient Flange Mount Assembly: Precision-machined standard flange bolt connection ensures rapid installation, precise axial alignment, and low maintenance downtime.

5. Smooth Operation & High Efficiency: Delivers optimal rotational stability and maximum drive efficiency under bidirectional starting and reversing conditions.

3. Technical Specifications & Model Specifications

Technical Parameters & Size Specifications

Standard SWC-WD Models

We offer complete standard model dimensions as well as custom non-standard manufacturing:

• Light / Medium Models: SWC100WD, SWC120WD, SWC150WD, SWC180WD

• Heavy-Duty Models: SWC225WD, SWC250WD, SWC285WD, SWC315WD (Up to SWC620WD)

(Note: Custom flange bolt patterns, keyways, special swing diameters, and tailored axial dimensions are available upon request.)

4. Target Industrial Applications

Where Are SWC-WD Cardan Shaft Couplings Applied?

Our heavy-duty cardan shaft assemblies are widely used across high-torque industrial machinery:

• Steel Rolling Mills & Metallurgical Processing Lines

• Heavy Mining Machinery & Crushing Equipment

• Paper Mill Drives & Industrial Mixers

• Rubber & Plastics Machinery (Extruders, Calenders)

• Crane Drive Systems & Marine Propulsion Units

5. B2B Inquiry Form

Request a B2B Quote for SWC-WD Cardan Shaft Couplings

Are you an OEM machinery manufacturer, steel mill engineer, or heavy equipment integrator looking for direct factory supply? Submit your technical parameters below for CAD selection and wholesale pricing.

• Contact Name & Company Name:

• Corporate Email Address:

• Target Model / Rotation Diameter (e.g., SWC180WD / SWC250WD):

• Operating Torque (kN·m), Speed (RPM) & Flange Bolt Specifications:

• Estimated Order Quantity (Sets):

• Upload Shaft Layout / CAD Drawing:
