H Series Steel Flexible Coupling - High Torque Spider Coupler with 10mm Bore, 1000Nm Capacity
- Phone : +86 13431039760
- Wechat : +86 13431039760
- Whatsapp : +86 13431039760
- Email : ella@apexcoupling.com
Product Description
| Feature | Description |
|---|---|
| Excellent Flexibility | Spider element compensates for shaft misalignment and absorbs vibrations |
| High Torque Capacity | Rated for 1000 N·m torque transmission in demanding applications |
| High-Speed Operation | Suitable for speeds up to 2000 RPM for various industrial uses |
| Compact Design | Space-saving construction with standard 10mm bore size |
| Easy Installation | Simple assembly without special tools required |
| Low Maintenance | No lubrication needed, reducing downtime and operating costs |
| Durable Construction | Steel body ensures long service life in harsh environments |
Product Details
| Specification | Details |
|---|---|
| Product Name | H Series Flexible Spider Coupling |
| Model | H Type (80, 95, 110, 125, 140, 160, 180) |
| Bore Diameter | 10mm (Standard) |
| Rated Torque | 1000 N·m |
| Maximum Speed | 2000 RPM |
| Material | Steel |
| Structure | Single/Double Spider Design |
| Type | Flexible |
| Standard | Standard dimensions |
| Customization | OEM, ODM, OBM support available |
| Warranty | 1 Year |
Product Applications
| Industry | Specific Applications |
|---|---|
| Machinery Repair Shops | Replacement parts for industrial equipment maintenance |
| Manufacturing Plants | Conveyor systems, production line equipment |
| Material Handling | Pumps, compressors, fans and blowers |
| Industrial Machinery | Textile machines, packaging equipment, printing machinery |
| General Power Transmission | Various mechanical systems requiring flexible shaft connections |
Additional Information
Place of Origin:Â Guangdong, China
Selling Units:Â Single item
Technical Support:Â Comprehensive engineering consultation available
Custom Solutions:Â Special sizes and configurations upon request
Quality Assurance:Â Strict quality control ensures reliable performance
Product Show
Steel H Type 80 95 110 125 140 160 180 N-EUPEX Flexible Couplings H Spider 10mm Bore 1000 Nm Torque 2000 RPM
